With only 100 ever produced, I’m not really sure who wants (or needs) detailed side view illustrations of the British Aerospace Jetstream 41. No matter. There was very little that could’ve stopped me from spending the last three weeks of my life creating the set of drawings you see below.
Side view templates of the British Aerospace Jetstream 41
There’s a lot about the Jetstream 41 to like. It’s a fairly good looking turboprop IMHO, with decent proportions and nothing that looks too far out of the ordinary (something I can’t say about the Beechcraft 1900D). Most importantly? There were no variants. It was one design. One configuration. That’s all they ever made.
Because the Jetstream 41 was the evolution of the Jetstream 31 (an aircraft which first flew in 1980), some of the design elements seem a bit dated for a 1990s aircraft. For example, the cockpit windows are tall and upright.
That (combined with the overall shape of the stubby fuselage) gave it a bit of a “classic” look – at least compared to similar aircraft of the time.
Fully editable 5000 x 3000 px high-resolution source files for these templates are available! Get them in JPG, PNG, PSD, and vector format.
The most interesting design elements
Let’s face it. The J41 is pretty darn far from being one of the best looking aircraft ever made. That said, it has some redeeming qualities:
- The most fascinating thing about the Jetstream 41 design (at least it to me anyway) is the fact that the fuselage was an entirely new design – even though it was based on an existing aircraft (the Jetstream 31).
- Speaking of the fuselage, the sectioning (as you can see above in the line drawing) is relatively simple for an aircraft of this type. There appears to be the typical amount of panel lines near the front of the fuselage, but it gets a lot simpler towards the back near the cargo door.
- The horizontal stabilizer seems small for an aircraft of this size. It’s obviously sufficient, but the visual designer in me feels like it needs to be at least 50% larger to match the proportions of the surrounding elements.
- It’s a lot lower than it looks. The very tip of the vertical stabilizer measures 18′-10″ off the ground – which is 22′ lower than the Boeing 737 MAX 8.
Finally, I am of the opinion that the Allied Signal TPE331-14 engines sound really nice. I distinctly recall being enamored by the sound of a Trans World Express Express J41 buzzing past me at STL sometime in the mid 90s. It sounded good.
I hope you’re able to do something amazing with these illustrations!
